LDPlayer live game and OBS streaming tutorial

In a sentence: Use LDPlayer to run mobile games on a computer, then use OBS Studio's "Window Capture" to capture the simulator screen, add sound collection, fill in the push address and streaming code of the live broadcast platform (Douyin/Bilibili/Douyu) and start broadcasting - a large screen, stable image quality, and the ability to add cameras and barrage, which is much clearer than mobile live broadcasts.
Key points of this article
- 1. Can LDPlayer live stream mobile games?
- 2. Use OBS to capture the simulator window push stream
- 3. Picture quality and frame rate settings for live broadcast without lag
- 4. How to live stream mobile vertical screen games to make them look good
- 5. What should I do if my live broadcast has a black screen, no sound, and high latency?
1.Can LDPlayer live stream mobile games?
Yes, and it is one of the mainstream methods of mobile game live streaming. LDPlayer runs mobile games on a computer. It has a large screen, requires a keyboard and mouse to operate, and has more stable performance than a mobile phone. With streaming software such as OBS,You can play and live broadcast with just one computer, and can also overlay cameras, text, and barrages. Regardless of Genshin Impact, King of Kings or idle games, it is easier and clearer than using a mobile phone to cast a live broadcast.
2.Use OBS to capture the simulator window push stream
Click + on "Source" in OBS and select window capture, select LDPlayer in the window; if a black screen is captured, change the capture mode from "Auto" to "Windows 10/BitBlt" and try one more. For sound, use "Application Audio Capture" to capture the sound of the simulator alone to avoid recording other sounds from the computer. Adjust the picture to crop it so that only the game area is left, and the composition will be clean.
Three.Picture quality and frame rate settings for live broadcast without lag
The code rate is 4000–6000kbps, the resolution is 1080p/720p, and the frame rate is 60, which is a safe file for most platforms.
Stuttering in live streaming is most likely caused by the bit rate being too high or the computer being unable to power it. Encoder priority in OBS outputGraphics card hardware encoding (NVENC/AMD/QSV), save CPU; if the uplink bandwidth is not enough, reduce the bit rate to below 4000. The simulator itself must first enable VT and provide sufficient CPU/memory, seeCaton optimization guide, the source is not stuck, the live broadcast is not stuck.
Four.How to live stream mobile vertical screen games to make them look good
Vertical screen mobile games (such as most two-dimensional and idle games) will directly push the full screen to have big black borders on both sides. Solution: Set the resolution to vertical screen (such as 1080×1920) in the simulator, center the vertical window in OBS, and leave space on both sides for game graphics, cameras or barrage, so that the screen will not be empty. For horizontal screen games (Genshin Impact/King of Kings), just use the horizontal screen resolution to cover the whole area.
5.What should I do if my live broadcast has a black screen, no sound, and high latency?
OBS captureblack screen→Change the capture method or use "Monitor Capture" for cropping;No sound→Check that "Application Audio Capture" has selected the correct simulator and the platform is not muted;High latency/dropped frames→Reduce the code rate, turn on hardware encoding, and turn off other computer programs that occupy the network and graphics card. First ensure that the simulator itself is smooth (turn on VT, control the number of multi-turns), and then adjust OBS.
Source:LDPlayer official website · OBS streaming is a general live broadcast solution, and the specific parameters are adjusted according to the platform and bandwidth.
Performance and Live Broadcast FAQ (8 Article)
How to enter BIOS and enable VT on LDPlayer on ASUS/MSI/GIGABYTE motherboards?
The idea is the same, but the buttons and menu names are slightly different. When turning on the computer, press the key to enter the BIOS: Del for ASUS, MSI, and Gigabyte desktop computers, and F2 for some notebooks. After entering, look for the virtualization item: Look for "Intel Virtualization Technology / Intel VT-x" on the Intel platform, usually under Advanced or CPU Configuration; look for "SVM Mode" on the AMD platform, usually under OC or Advanced CPU Settings. Change it to Enabled, F10 to save and restart. The BIOS interfaces of different motherboards vary greatly. If you can't find it, search "Model + Enable VT" by the motherboard model. After opening, the VT prompt of LDPlayer will turn green. The simulator can be downloaded from ldmqn.com.
LDPlayer gets hot when playing games and the fan spins wildly. Will long-term use damage the computer?
When playing large-scale games, it is normal for the CPU/GPU to heat up and the fan to spin up when fully loaded, which is similar to playing PC games directly. As long as the heat dissipation is normal and the temperature is within a safe range (no frequent overheating, frequency reduction or crash), occasional playing will not cause any special harm to the computer. To cool down: ① Turning on VT can significantly reduce CPU usage and heat generation; ② Reduce the frame rate/resolution appropriately; ③ Clean the desktop, use a cooling pad to elevate the notebook, connect the power supply to turn on the performance but pay attention to heat dissipation; ④ Do not open it for a long time under high load. If the temperature is abnormally high, optimize the settings before playing. Adjust the performance well and LDPlayer will be smooth without burning the machine all the time. The simulator can be updated to the latest version at ldmqn.com.
When LDPlayer plays games, other computer operations become laggy. How to balance it?
Emulators (especially multiple/large-scale games) will occupy a lot of CPU, memory and graphics card, resulting in lag when doing other things at the same time. Balancing method: ① Don’t overfill the CPU cores and memory allocation in the simulator settings, leaving room for the system and other programs; ② When high frame/high resolution is not needed, lower it to reduce the load; ③ When not playing, completely close the simulator and multi-opener, and don’t let it occupy resources in the background; ④ Use the task manager to set the emulator process priority to "Normal" to prevent it from grabbing up resources (on the contrary, if you want the game to be smoother, increase it); ⑤ If the machine's memory is too small, don't open it too much. Allocate resources according to whether you "focus on playing" or "work while playing". Download LDPlayer from ldmqn.com.
Will LDPlayer slow down other software on my computer if VT is turned on?
No. VT is just a virtualization switch for the CPU and usually does not occupy resources. When the computer becomes slow, it is usually because LDPlayer is running and robs the CPU and memory. Turn off the emulator and it will recover. So don't worry about turning on VT. It is the prerequisite for LDPlayer to run smoothly and occupy less resources.
LDPlayer requires VT, but what should I do if I still need to use Hyper-V/WSL/Docker?
All of these require hardware virtualization, which often conflicts with LDPlayer. Generally, you have to choose one of two options: turn off Hyper-V when playing LDPlayer, turn it back on when you want to use WSL/Docker, switch and restart as needed. If both parties want to keep it open for a long time, it is often a struggle. It is recommended to switch according to the usage scenario for the most worry-free time.
Has LDPlayer enabled VT or can it only enable one and not more?
It may be that Hyper-V or memory integrity is not turned off cleanly, accounting for virtualization, or there is not enough memory. Turn off these conflicting items, leave enough memory for LDPlayer, and adjust the resources allocated to a single window too high. If you open it more often, it will usually work normally. If it still doesn’t work, go to ldmqn.com to update to the latest version and try again.
How many cores of CPU and how many G of memory are best for LDPlayer?
The rule of thumb is to give about half of the physical configuration (for example, give LDPlayer 2-core 4G for a 4-core 8G machine), don’t fill it up, and leave some margin for the system; when playing large-scale games, you can increase the amount appropriately, and if you open more, adjust each window to a smaller size, so as not to add up to drain the computer. The same allocation will be more efficient after turning on VT.
Can LDPlayer be played with integrated graphics/core graphics?
It can be played, but it is difficult for LDPlayer to run large-scale 3D games on the core display. It is recommended to select OpenGL for the rendering mode and lower the image quality; the core display is sufficient for playing light games such as 2D, cards, and chess. To play masterpieces, it is more stable to use a discrete graphics card. Turn on VT first, and the graphics card will be less stuck.
